XJP-17AT/17BT METALLURGICAL MICROSCOPE
XJP-17 metallurgical microscopes are used for identification and
analysis of the structures in different metals and alloys. They are
the important instruments for researching metallography in
metal physics. The instruments can select special photography
device to take euploid pictures of atlas metallograph. The
instruments are suitable for scientific research,colleges and
factory.
FEATURES
■ With plan achromatic objectives with long working distance (no
  cover glass) and wide-field eyepieces, can get clear pictures and
  wide view field.
■ Coaxial coarse/fine focus system, with tension adjustable and up
  stop, minimum division of fine focusing: 2μm.
■ 6V 20W halogen lamp, brightness control.
■ Trinocular is compensation, can switch to observe normally or to
  observe the Polarize, can send 100% of light to top photography
  port.

Observation System
■ Binocular，single diopter adjustment,inclined 30° , comfortable
  & good- looking.Trinocular can be connected to the camera.
  10X wide field plan eyepiece, field Ø18mm，can provide an
  expanse and smooth space for observation.



Mechanical Stage
■ The circular chromeplate substage is located in the center of
  mechanical stage so that enable rotate the specimen in the
  polarization observation.


Illumination System
■ Integrated illumination can make upthe difference of halogens
  by adjusting the spacial position. The illumination mode is“
  Kohler illumination” .and the adjustment of field and aperture
  diaphragm is achieved by turning the control plate,by adding
  the flashboard ploarizer can be rotated from 0°~90° . the
  adjustment mode is smooth and comfort.


Photography Unit
■ By adding the appurtenance such as CCD adapter, digital
  camera adapter and single- reverse digital camera adapter and
  etc. It can achieve high clear observation mode of camera and
  vidicon

Digital camera photography:




       Polarized observe                            Bright type observe   Bright type observe
