XJP-17AT/17BT METALLURGICAL MICROSCOPE
XJP-17 metallurgical microscopes are used for identification and
analysis of the structures in different metals and alloys. They are
the important instruments for researching metallography in
metal physics. The instruments can select special photography
device to take euploid pictures of atlas metallograph. The
instruments are suitable for scientific research,colleges and
factory.
FEATURES
■ With plan achromatic objectives with long working distance (no
  cover glass) and wide-field eyepieces, can get clear pictures and
  wide view field.
■ Coaxial coarse/fine focus system, with tension adjustable and up
  stop, minimum division of fine focusing: 2μm.
■ 6V 20W halogen lamp, brightness control.
■ Trinocular is compensation, can switch to observe normally or to
  observe the Polarize, can send 100% of light to top photography
  port.

Observation System
■ Binocular，single diopter adjustment,inclined 30° , comfortable
  & good- looking.Trinocular can be connected to the camera.
  10X wide field plan eyepiece, field Ø18mm，can provide an
  expanse and smooth space for observation.



Mechanical Stage
■ The circular chromeplate substage is located in the center of
  mechanical stage so that enable rotate the specimen in the
  polarization observation.


Illumination System
■ Integrated illumination can make upthe difference of halogens
  by adjusting the spacial position. The illumination mode is“
  Kohler illumination” .and the adjustment of field and aperture
  diaphragm is achieved by turning the control plate,by adding
  the flashboard ploarizer can be rotated from 0°~90° . the
  adjustment mode is smooth and comfort.


Photography Unit
■ By adding the appurtenance such as CCD adapter, digital
  camera adapter and single- reverse digital camera adapter and
  etc. It can achieve high clear observation mode of camera and
  vidicon

Digital camera photography:




       Polarized observe                            Bright type observe   Bright type observe



                                                                                                J15

--- KATALOG SAYFA 17 ---
TECHNICAL SPECIFICATION
      Model No.                                               XJP-17AT                                 XJP-17BT
      Eyepiece                                 Wide field WF10X(Φ18mm)
                                             Plan achromatic objectives with long
                                             working distance (no cover glass) PL        Achromatic objectives(no cover
                                             10X/0.25                                    glass) 10X/0.25
                                             Plan achromatic objectives with long
                                             working distance (no cover glass) PL        Achromatic objectives(no cover
                                             L20X/0.40                                   glass) 20X/0.40
      Objective                              Plan achromatic objectives with long
                                             working distance (no cover glass) PL        Achromatic objectives(no cover
                                             L40X/0.60                                   glass) SP 40X/0.65
                                             Plan achromatic objectives with long
                                             working distance (no cover glass) PL        Achromatic objectives(no cover
                                             100X/1.25(Spring, oil)                      glass) 100X/1.25(Spring, oil)
      Eyepieces tube                          Trinocular, Inclination of 30˚
                                              Blue filter
      Filter                                  Green filter
                                              Yellow filter
                                              Coaxial coarse/fine focus system, with tensional adjustable and up stop,
      Focus system                            minimum division of fine focusing: 2μm.
      Nosepiece                               Quadruple(Ball bearing inner locating)
      Stage                                   Double layer mechanical (Size:180mmX150mm,moving range:15mmX15mm)
      Illumination                            6V 20W halogen lamp, brightness control.


         INVERTED METALLURGICAL MICROSCOPE XJP-420
      FEATURES:
      ■ XJP-420 Infinitive Optical System Providing Excellent Optical Functions.
         With the stable stand structure, advanced stage design and comfortable
         operation, it is widely used in institute and laboratory to observe and
         identify the structure of various metal and alloy.

      TECHNICAL SPECIFICATION

          Eyepiece             High-point , extra wide field eyepiece EW10×/ 20
                               Inifitive Plan achromatic objective 4X/0.1
                               Inifitive Plan achromatic objective10X/0.25
          Objectives
                               Inifitive Plan achromatic objective20X/0.4(s)
                               Inifitive Plan achromatic objective 40X/0.6
          Viewing Head          Inclined 30°, interpupillary distance 48-75mm
                                Coaxial coarse & fine adjustment, Vertical objective movement,
          Focusing              Coarse stroke 37.7mm per rotation, Fine stroke 0.2mm per rotation
                               Plain stage, stage layer Ø110mm, hole Ø10mm,Ø15mm,Ø25mm
       Mechanical Stage
                               Moving range 120X78mm,loading plate 128X86mm
           Nosepiece            Quintuple Nosepiece
           Illuminator         6V/30W Halogen Lamp,Adjustable
           Color Filter         Yellow, Blue , Green Color Filter, Ground Glass
          Power Supply          AC220V/50Hz;110V/60Hz

      OPTIONAL ACCESSORY
                          Product Name                                         Product Name
                Infinite Plan Achormatic 5x/0.25                    Infinite Plan Achormatic 80x/0.9
               Infinite Plan Achormatic 100X/0.80                        Mechanical 226x178mm
          1xC-mount(Available for Digital Camera)                         USB Camera USB-A1
